Those who have read my blog posts over the years will have seen the image to the left.

The people, processes and tools slogan points to the best practice of implementing (PLM and CM) systems.

Theoretically, a PLM implementation will move smoothly if the company first agrees on the desired processes and people involved before a system implementation using the right tools.

Too often, companies start from their historical landscape (the tools – starting with a vendor selection) and then try to figure out the optimal usage of their systems. The best example of this approach is the interaction between PDM(PLM) and ERP.



PDM and ERP

Historically ERP was the first enterprise system that most companies implemented. For product development, there was the PDM system, an engineering tool, and for execution, there was the ERP system. Since ERP focuses on the company’s execution, the system became the management’s favorite.

The ERP system and its information were needed to run and control the company. Unfortunately, this approach has introduced the idea that the ERP system should also be the source of the part information, as it was often the first enterprise system for a company. The PDM system was often considered an engineering tool only. And when we talk about a PLM system, who really implements PLM as an enterprise system or was it still an engineering tool?

This is an example of Tools, Processes, and People – A BAD PRACTICE.

Imagine an engineer who wants to introduce a new part needed for a product to deliver. In many companies at the beginning of this century, even before starting the exercise, the engineer had to request a part number from the ERP system. This is implementation complexity #1.

Next, the engineer starts developing versions of the part based on the requirements. Ultimately the engineer might come to the conclusion this part will never be implemented. The reserved part number in ERP has been wasted – what to do?

It sounds weird, but this was a reality in discussions on this topic until ten years ago.

Next, as the ERP system could only deal with 7 digits, what about part number reuse? In conclusion, it is a considerable risk that reused part numbers can lead to errors. With the introduction of the PLM systems, there was the opportunity to bridge the gap between engineering and manufacturing. Now it is clear for most companies that the engineer should create the initial part number.

Only when the conceptual part becomes approved to be used for the realization of the product, an exchange with the ERP system will be needed. Using the same part number or not, we do not care if we can map both identifiers between these environments and have traceability.

It took almost 10 years from PDM to PLM until companies agreed on this approach, and I am curious about your company’s status.

Meanwhile, in the PLM world, we have evolved on this topic. The part and the BOM are no longer simple entities. Instead, we often differentiate between EBOM and MBOM, and the parts in those BOMs are not necessarily the same.

In this context, I like Prof. Dr. Jörg W. Fischer‘s framing:
EBOM is the specification, and MBOM is the realization.
(Leider schreibt Er viel auf Deutsch).

An interesting discussion initiated by Jörg last week was again about the interaction between PLM and ERP. The article is an excellent example of how potentially mainstream enterprises are thinking. PLM = Siemens, ERP = SAP – an illustration of the “tools first” mindset before the ideal process is defined.

There was nothing wrong with that in the early days, as connectivity between different systems was difficult and expensive. Therefore people with a 20 year of experience might still rely on their systems infrastructure instead of data flow.

But enough about the bad practice – let’s go to people, processes, (data), and Tools

People, Processes, Data and Tools?

I got inspired by this topic, seeing this post two weeks ago from Juha Korpela, claiming:

Okay, so maybe a hot take, maybe not, but: the old “People, Process, Technology” trinity is one of the most harmful thinking patterns you can have. It leaves out a key element: Data.

His full post was quite focused on data, and I liked the ” wrapping post” from Dr. Nicolas Figay here, putting things more in perspective from his point of view. The reply made me think about how this discussion fits into the PLM digital transformation discussion. How would it work in the two major themes I use to explain the digital transformation in the PLM landscape?

For incidental readers of my blog, these are the two major themes I am using:

  1. From Coordinated to Connected, based on the famous diagram from Marc Halpern (image below). The coordinated approach based on documents (files) requires a particular timing (processes) and context (Bills of Information) – it is the traditional and current PLM approach for most companies. On the other hand, the Connected approach is based on connected datasets (here, we talk about data – not files). These connected datasets are available in different contexts, in real-time, to be used by all kinds of applications, particularly modeling applications. Read about it in the series: The road to model-based and connected PLM.
    .
  2. The need to split PLM, thinking in System(s) of Record and Systems of Engagement. (example below) The idea behind this split is driven by the observation that companies need various Systems of Record for configuration management, change management, compliance and realization. These activities sound like traditional PLM targets and could still be done in these systems. New in the discussion is the System of Engagement which focuses on a specific value stream in a digitally connected manner. Here data is essential.I discussed the coexistence of these two approaches in my post Time to Split PLM. A post on LinkedIn with many discussions and reshares illustrating the topic is hot. And I am happy to discuss “split PLM architectures” with all of you.

These two concepts discuss the processes and the tools, but what about the people? Here I came to a conclusion to complete the story, we have to imagine three kinds of people. And this will not be new. We have the creators of data, the controllers of data and the consumers of data. Let’s zoom in on their specifics.



A new representation?

I am looking for a new simplifaction of the people, processes, and tools trinity combined with data; I got inspired by the work Don Farr did at Boeing, where he worked on a new visual representation for the model-based enterprise. You might have seen the image on the left before – click on it to see it in detail.

I wrote the first time about this new representation in my post: The weekend after CIMdata Roadmap / PDT Europe 2018

Related to Configuration Management, Martijn Dullaart and Martin Haket have also worked on a diagram with their peers to depict the scope of CM and Impact Analysis. The image leads to the post with my favorite quote: Communication is merely an exchange of information, but connections tell the story.

Below I share my first attempt to combine the people, process and tools trinity with the concepts of document and data, system(s) of record and system(s) of engagement. Trying to build the story.  Look if you recognize the aspects of the discussion above, and feel free to develop enhancements.

I look forward to your suggestions. Like the understanding that we have to split PLM thinking, as it impacts how we look at implementations.

Conclusion

Digital transformation in the PLM domain is forcing us to think differently. There will still be processes based on people collecting, interpreting and combining information. However, there will also be a new domain of connected data interpreted by models and algorithms, not necessarily depending on processes.

Therefore we need to work on new representations that can be used to tell this combined story. What do you think? How can we improve?



My last blog post was about reasons why PLM is not simple. PLM supporting a well-planned business transformation requires business change / new ways of working. PLM is going through different stages. We are moving from drawing-centric (previous century), through BOM-centric (currently) towards model-centric (current and future). You can read the post here: PLM is not simple!

I was happy to see  my blog buddy Oleg Shilovitsky chimed in on this theme, with his post: Who needs Simple PLM? Oleg reviewed the stakeholders around a PLM implementation. An analytical approach which could be correct in case predictive human beings were involved. Since human beings are not predictive and my focus is on the combination of PLM and human beings, here are some follow comments on the points Oleg made:



Customers (Industrial companies)

Oleg wrote:

A typical PLM customer isn’t a single user. A typical PLM buyer is engineering IT organization purchasing software to solve business problem. His interest to solve business problem, but not really to make it simple. Complex software requires more people, an increased budget and can become an additional reason to highlight IT department skills and experience. End-users hate complex software these days,therefore, usability is desired, but not top priority for enterprise PLM.

My comments on this part: PLM becomes more and more an infrastructure for product information along the whole lifecycle. PLM is no longer an engineering tool provided by IT.

There are now many other stakeholders that need product data, in particular when we are moving to a digital enterprise. A model-based approach connects Manufacturing and Service/Operations through a digital thread. It is the business demanding for PLM to manage their complexity. IT will benefit from a reduction in silo applications.



PLM Vendors

Oleg wrote:

…most PLM vendors are far away from a desired level of simplicity. Marketing will like “simple” messages, but if you know how to sell complex software, you won’t be much interested to see “simple package” everyone can sell. However, for the last decade, PLM vendors were criticized a lot for complexity of their solutions, so they are pretty much interested how to simplify things and present it as a competitive differentiation.



Here we are aligned. All PLM vendors are dreaming of simplifying their software. Imagine: if you have a simple product everyone can use, you would be the market leader and profitable like crazy without a big effort as the product is simple. Of course, this only works, assuming this dream can be realized.

Some vendors believe that easy customization or configuration of the system means simplification. Others believe a simple user-interface is the key differentiator. Compared to mass-consumer software products in the market, a PLM system is still a niche product, with a limited amount of users working with the exact same version of the software. Combined with the particular needs (customizations) every company has (“we are different”), there will never be a simple PLM solution. Coming back to the business transformation theme, human beings are the weakest link.



Implementation and Service Providers

Oleg wrote:

Complex software, customization, configuration, know-hows, best practices, installation… you name it.More of these things can only lead to more services which is core business of PLM service providers. PLM industry is very much competitive, but simplicity is not a desired characteristic for PLM when it comes to service business. Guess what… customer can figure it out how to make it and stop paying for services.

Here we are totally aligned. In the past, I have been involved in potential alliances where certain service providers evaluated SmarTeam as a potential tool for their business. In particular, the major PLM service providers did not see enough value in an easy to configure and relatively cheap product. Cheap means no budget for a huge amount of services.

Still, the biggest problem SmarTeam had after ten years was the fact that every implementation became a unique deployment. Hard to maintain and guarantee for the future. In particular, when new functionality was introduced which potentially already existed as customization.  Implementation and service providers will never say NO to a customer when it comes to further customization of the system. Therefore, the customer should be in charge and own the implementation. For making strategic decision support can come from a PLM consultant or coach.



PLM Consultants

Here Oleg wrote:

Complex software can lead to good consulting revenues. It was true many years for enterprise software. Although, most of PLM consultants are trying to distant from PLM software and sell their experience “to implement the future”, simplicity is not a favorite word in consulting language. Customer will hire consulting people to figure out the future and how to transform business, but what if software is simple enough to make it happen without consultant? Good question to ask, but most of them will tell you it is not a realistic scenario. Which is most probably true today. But here is the hint – remember the time PC technicians knew how to configured jumpers on PC cards to make printer actually print something?

Here we are not aligned. Business transformations will never happen because of simple tools. People are measured and pushed to optimize their silos in the organization. A digital transformation, which is creating a horizontal flow and transparency of information, will never happen through a tool. The organization needs to change, and this is always driven by a top-down strategy. PLM consultants are valuable to explain the potential future, to coach all levels of the organization. In theory, a PLM consultant’s job is tool independent. However, the challenge of being completely disconnected from the existing tools might allow for dreams that never can be realized. In reality, most PLM consultants are experienced in one or more specific tools they have been implementing. The customer should be aware of that and make sure they own the PLM roadmap.

My conclusion:

Don’t confuse PLM with a tool, simple or complex. All PLM tools have a common base and depending on your industry and company’s vision there will be a short list. However, before you touch the tools, understand your business and the transformation path you want to take. And that is not simple !!



Your opinion?

Oleg and I can continue this debate for a long time.  We would be interested in learning your view on PLM and Simplicity – please tune in through the comments section below:
