You are currently browsing the category archive for the ‘Digital enterprise’ category.

This is my concluding post related to the various aspects of the model-driven enterprise. We went through Model-Based Systems Engineering (MBSE) where the focus was on using models (functional / logical / physical / simulations) to define complex product (systems). Next we discussed Model Based Definition / Model-Based Enterprise (MBD/MBE), where the focus was on data continuity between engineering and manufacturing by using the 3D Model as a master for design, manufacturing and eventually service information.

And last time we looked at the Digital Twin from its operational side, where the Digital Twin was applied for collecting and tuning physical assets in operation, which is not a typical PLM domain to my opinion.

Now we will focus on two areas where the Digital Twin touches aspects of PLM – the most challenging one and the most over-hyped areas I believe. These two areas are:

  • The Digital Twin used to virtually define and optimize a new product/system or even a system of systems. For example, defining a new production line.
  • The Digital Twin used to be the virtual replica of an asset in operation. For example, a turbine or engine.

Digital Twin to define a new Product/System

There might be some conceptual overlap if you compare the MBSE approach and the Digital Twin concept to define a new product or system to deliver. For me the differentiation would be that MBSE is used to master and define a complex system from the R&D point of view – unknown solution concepts – use hardware or software?  Unknown constraints to be refined and optimized in an iterative manner.

In the Digital Twin concept, it is more about a defining a system that should work in the field. How to combine various systems into a working solution and each of the systems has already a pre-defined set of behavioral / operational parameters, which could be 3D related but also performance related.

You would define and analyze the new solution virtual to discover the ideal solution for performance, costs, feasibility and maintenance. Working in the context of a virtual model might take more time than traditional ways of working, however once the models are in place analyzing the solution and optimizing it takes hours instead of weeks, assuming the virtual model is based on a digital thread, not a sequential process of creating and passing documents/files. Virtual solutions allow a company to optimize the solution upfront instead of costly fixing during delivery, commissioning and maintenance.

Why aren’t we doing this already? It takes more skilled engineers instead of cheaper fixers downstream. The fact that we are used to fixing it later is also an inhibitor for change. Management needs to trust and understand the economic value instead of trying to reduce the number of engineers as they are expensive and hard to plan.

In the construction industry, companies are discovering the power of BIM (Building Information Model) , introduced to enhance the efficiency and productivity of all stakeholders involved. Massive benefits can be achieved if the construction of the building and its future behavior and maintenance can be optimized virtually compared to fixing it in an expensive way in reality when issues pop up.

The same concept applies to process plants or manufacturing plants where you could virtually run the (manufacturing) process. If the design is done with all the behavior defined (hardware-in-the-loop simulation and software-in-the-loop) a solution has been virtually tested and rapidly delivered with no late discoveries and costly fixes.

Of course it requires new ways of working. Working with digital connected models is not what engineering learn during their education time – we have just started this journey. Therefore organizations should explore on a smaller scale how to create a full Digital Twin based on connected data – this is the ultimate base for the next purpose.

Digital Twin to match a product/system in the field

When you are after the topic of a Digital Twin through the materials provided by the various software vendors, you see all kinds of previews what is possible. Augmented Reality, Virtual Reality and more. All these presentations show that clicking somewhere in a 3D Model Space relevant information pops-up. Where does this relevant information come from?

Most of the time information is re-entered in a new environment, sometimes derived from CAD but all the metadata comes from people collecting and validating data. Not the type of work we promote for a modern digital enterprise. These inefficiencies are good for learning and demos but in a final stage a company cannot afford silos where data is collected and entered again disconnected from the source.

The main problem: Legacy PLM information is stored in documents (drawings / excels) and not intended to be shared downstream with full quality.
Read also: Why PLM is the forgotten domain in digital transformation.

If a company has already implemented an end-to-end Digital Twin to deliver the solution as described in the previous section, we can understand the data has been entered somewhere during the design and delivery process and thanks to a digital continuity it is there.

How many companies have done this already? For sure not the companies that are already a long time in business as their current silos and legacy processes do not cater for digital continuity. By appointing a Chief Digital Officer, the journey might start, the biggest risk the Chief Digital Officer will be running another silo in the organization.

So where does PLM support the concept of the Digital Twin operating in the field?

For me, the IoT part of the Digital Twin is not the core of a PLM. Defining the right sensors, controls and software are the first areas where IoT is used to define the measurable/controllable behavior of a Digital Twin. This topic has been discussed in the previous section.

The second part where PLM gets involved is twofold:

  • Processing data from an individual twin
  • Processing data from a collection of similar twins

Processing data from an individual twin

Data collected from an individual twin or collection of twins can be analyzed to extract or discover failure opportunities. An R&D organization is interested in learning what is happening in the field with their products. These analyses lead to better and more competitive solutions.

Predictive maintenance is not necessarily a part of that.  When you know that certain parts will fail between 10.000 and 20.000 operating hours, you want to optimize the moment of providing service to reduce downtime of the process and you do not want to replace parts way too early.


The R&D part related to predictive maintenance could be that R&D develops sensors inside this serviceable part that signal the need for maintenance in a much smaller time from – maintenance needed within 100 hours instead of a bandwidth of 10.000 hours. Or R&D could develop new parts that need less service and guarantee a longer up-time.

For an R&D department the information from an individual Digital Twin might be only relevant if the Physical Twin is complex to repair and downtime for each individual too high. Imagine a jet engine, a turbine in a power plant or similar. Here a Digital Twin will allow service and R&D to prepare maintenance and simulate and optimize the actions for the physical world before.

The five potential platforms of a digital enterprise

The second part where R&D will be interested in, is in the behavior of similar products/systems in the field combined with their environmental conditions. In this way, R&D can discover improvement points for the whole range and give incremental innovation. The challenge for this R&D organization is to find a logical placeholder in their PLM environment to collect commonalities related to the individual modules or components. This is not an ERP or MES domain.

Concepts of a logical product structure are already known in the oil & gas, process or nuclear industry and in 2017 I wrote about PLM for Owners/Operators mentioning Bjorn Fidjeland has always been active in this domain, you can find his concepts at plmPartner here  or as an eLearning course at SharePLM.

To conclude:

  • This post is way too long (sorry)
  • PLM is not dead – it evolves into one of the crucial platforms for the future – The Product Innovation Platform
  • Current BOM-centric approach within PLM is blocking progress to a full digital thread

More to come after the holidays (a European habit) with additional topics related to the digital enterprise



Advertisements

(Image courtesy of Loginworks.com)

This is almost my last planned post related to the concepts of model-based. After having discussed Model-Based Systems Engineering (needed to develop complex products/systems including hardware and software) and Model-Based Definition (creating an efficient connection between Engineering and Manufacturing), my last post will be related to the most over-hyped topic: The Digital Twin

There are several reasons why the Digital Twin is over-hyped. One of the reasons is that the Digital Twin is not necessarily considered as a PLM-related topic. Other vendors like SAP (the network of digital twins), Oracle (Digital Twins for IoT applications)  and GE with their Predix-platform also contributed to the hype related to the digital twin. The other reason is that the concept of Digital Twin is a great idea for marketers to shine above the clouds. Are recent comment from Monica Schnitger says it all in her post 5 quick takeaways from Siemens Automation summit. Monica’s take away related to Digital Twin:

The whole digital twin concept is just starting to gain traction with automation users. In many cases, they don’t have a digital representation of the equipment on their lines; they may have some data from the equipment OEM or their automation contractors but it’s inconsistent and probably incomplete. The consensus seemed to be that this is a great idea but out of many attendees’ immediate reach. [But it is important to start down this path: model something critical, gather all the data you can, prove benefit then move on to a bigger project.]

Monica is aiming to the same point I have been mentioning several times. There is no digital representation and the existing data is inconsistent. Don’t wait: The importance of accurate data – act now !

What is a digital twin?

I think there are various definitions of the digital twin and I do not want to go in a definition debate like we had before with the acronyms MBD/MBE (Model Based Definition/Enterprise – the confusion) or even the acronym PLM (classical PLM or digital PLM ?). Let’s agree on the following high-level statements:

  • A digital twin is a virtual representation of a physical product
  • The virtual part of the digital twin is defined by what you want to analyze, simulate, predict related to the physical product
  • One physical product can have multiple digital twins, only in the ideal world there is potentially a unique digital twin for every physical product in the world
  • When a product interacts with the environment, based on inputs and outputs, we normally call them systems. When I use Product, it will be most of the time a System, in particular in the context of a digital twin

Given the above statements, I will give some examples of digital twin concepts:

As a cyclist I am active on platforms like Garmin and Strava, using a tracking device, heart monitor and a power meter. During every ride my device plus the sensors measure my performance and all the data is uploaded to the platform, providing me with a report where I drove, how fast, my heartbeat, cadence and power during the ride. On Strava I can see the Flybys (other digital twins that crossed my path and their performances) and I can see per segment how I performed considered to others and I can filter by age, by level etc.)

This is the easiest part of a digital twin. Every individual can monitor and analyze their personal behavior and discover trends. Additionally, the platform owner has all the intelligence about all cyclists around the world, how they perform and what would be the best performance per location. And based on their Premium offering (where you pay) they can give you advanced advise on how you can improve. This is the Strava business model bringing value to the individual meanwhile learning from the behavior of thousands. Note in this scenario there is no 3D involved.

Another known digital twin story is related to plants in operation. In the past 10 years I have been advocating for Plant Lifecycle Management (PLM for Owner/Operators), describing the value of a virtual plant model using PLM capabilities combined with Maintenance, Repair and Overhaul (MRO) in order to reduce downtime. In a nuclear environment the usage of 3D verification, simulation and even control software in a virtual environment, can bring great benefit due to the fact that the physical twin is not always accessible and downtime can be up to several million per week.

The above examples provide two types of digital twins. I will discuss some characteristics in the next paragraphs.

Digital Twin – performance focus

Companies like GE and SAP focus a lot on the digital twin in relation to the asset performance. Measuring the performance of assets, compare their performance with other similar assets and based on performance characteristics the collector of the data can sell predictive maintenance analysis, performance optimization guidance and potentially other value offerings to their customers.

Small improvements in the range of a few percents can have a big impact on the overall net results. The digital twin is crucial in this business model to build-up knowledge, analyze and collect it and sell the knowledge again. This type of scenario is the easiest one. You need products with sensors, you need an infrastructure to collect the data and extract and process information in a manner that it can be linked to a behavior model with parameters that influence the model.

Image SAP blogs

This is the model-based part of the digital twin. For a single product there can be different models related to the parameters driving your business. E.g. performance parameters for output, parameters for optimal up-time (preventive maintenance – usage optimization) or parameters related to environmental impact, etc..) Building and selling the results of such a model is an add-on business, creating more value for your customer combined with creating more loyalty. Using the digital twin in the context of performance focus does not require a company to change the way they are working totally.  Yes, you need new skills, data collection and analysis, and more sensor technology but a lot of the product development activities can remain the same (for the moment).

As a conclusion for this type of digital twin I would state, yes there is some PLM involved, but the main focus is on business execution.

Due to the fact that I already reach more than 1000 words, I will focus in my next post on the most relevant digital twin for PLM. Here all disciplines come together. The 3D Mechanical model, the behavior models, the embedded and control software, (manufacturing) simulation and more. All to create an almost perfect virtual copy of a real product or system in the physical world. And there we will see that this is not as easy, as concepts depend on accurate data and reliable models, which is not the case currently in most companies in their engineering environment.



Conclusion

Digital Twin is a marketing hype however when you focus on only performance monitoring and tuning it becomes a reality as it does not require a company to align in a digital manner across the whole lifecycle. However this is just the beginning of a real digital twin.

Where are you in your company with the digital twin journey?

I was planning to complete the model-based series with a post related to the digital twin. However, I did not find the time to structure my thoughts to write it up in a structured story. Therefore, this time some topics I am working on that I would like to share.

Executive days at CADCAM Group

Last week I supported the executive days organized by the CADCAM Group in Ljubljana and Zagreb. The CADCAM is a large PLM Solution and Services Provider (60+ employees) in the region of South-East Europe with offices in Croatia, Slovenia, Serbia and Bosnia and Herzegovina. They are operating in a challenging region, four relative young countries with historically more an inside focus than a global focus. Many of CADCAM Group customers are in the automotive supply chain and to stay significant for the future they need to understand and develop a strategy that will help them to move forward.

My presentation was related to the learning path each company has to go through to understand the power of digital combined with the observation that current and future ways of working are not compatible therefore requiring a scaled and bimodal approach (see also PDT Europe further down this post).

This presentation matched nicely with Oscar Torres’s presentation related to strategy. You need to decide on the new things you are going to do, what to keep and what to stop. Sounds easy and of course the challenge is to define the what to start, stop and keep. There you need good insights into your current and future business.

Pierre Aumont completed the inspiring session by explaining how the automotive industry is being disrupted and it is not only Tesla. So many other companies are challenging the current status quo for the big automotive OEMs. Croatia has their innovator for electrical vehicles too, i.e. Rimac. Have a look here.

The presentations were followed by a (long) panel discussion. The common theme in both discussions is that companies need to educate and organize themselves to become educated for the future. New technologies, new ways of working need time and resources which small and medium enterprises often do not have. Therefore, universities, governments and interest groups are crucial.

A real challenge for countries that do not have an industrial innovation culture (yet).

CADCAM Group as a catalyst for these countries understands this need by organizing these executive days. Now the challenge is after these inspiring days to find the people and energy to follow-up.

Note: CADCAM Group graciously covered my expenses associated with my participation in these events but did not in any way influence the content of this paragraph.



The MBD/MBE discussion

In my earlier post, Model-Based: Connecting Engineering and Manufacturing,  I went deeper into the MBD/MBE topic and its potential benefits, closing with the request to readers to add their experiences and/or comments to MBD/MBE. Luckily there was one comment from Paul van der Ree, who had challenging experiences with MBD in the Netherlands. Together with Paul and a MBD-advocate (to be named) I will try to have discussion analyzing pro’s and con’s from all viewpoints and hopefully come to a common conclusion.

This to avoid that proponents and opponents of MBD just repeat their viewpoints without trying to converge. Joe Brouwer is famous for his opposition to MBD. Is he right or is he wrong I cannot say as there has never been a discussion. Click on the above image to see Joe’s latest post yourself. I plan to come back with a blog post related to the pro’s and con’s



The Death of PLM Consultancy

Early this year Oleg Shilovitsky and I had a blog debate related to the “Death of PLM Consultancy”. The discussion started here: The Death of PLM Consultancy ? and a follow-up post was PLM Consultants are still alive and have an exit strategy. It could have been an ongoing blog discussion for month where the value would be to get response from readers from our blogs.

Therefore I was very happy that MarketKey, the organizers behind the PLMx conferences in Europe and the US, agreed on a recorded discussion session during PLMx 2018 in Hamburg.  Paul Empringham was the moderator of this discussion with approx. 10 – 12 participants in the room to join the discussion. You can view the discussion here through this link: PLMx Hamburg debate

I want to thank MarketKey for their support and look forward to participating in their upcoming PLMx European event and if you cannot wait till next year, there is the upcoming PLMx conference in North America on November 5th and 6th – click on the image on the left to see the details.





PDT Europe call for papers

As you might have noticed I am a big supporter of the joint CIMdata/PDT Europe conference. This year the conference will be in Stuttgart on October 24th (PLM Roadmap) and October 25th (PDT).

I believe that this conference has a more “geeky” audience and goes into topics of PLM that require a good base understanding of what’s happening in the field. Not a conference for a newcomer in the world of PLM, more a conference for an experienced PLM person (inside a company or from the outside) that has experience challenging topics, like changing business processes, deciding on new standards, how to move to a modern digital business platform.

It was at these events where concepts as Model-Based were discussed in-depth, the need for Master Data Management, Industry standards for data exchange and two years ago the bimodal approach, also valid for PLM.

I hope to elaborate on experiences related to this bimodal or phased approach during the conference. If you or your company wants to contribute to this conference, please let the program committee know. There is already a good set of content planned. However, one or two inspiring presentations from the field are always welcome.
Click on this link to apply for your contribution

Conclusion

There is a lot on-going related to PLM as you can see. As I mentioned in the first topic it is about education and engagement. Be engaged and I am looking forward to your response and contribution in one or more of the topics discussed.

Model-based continued: Model-Based Definition

After a short celebration, 10 years blogging and 200 posts, now it is time to continue my series related to the future of model-based. So far my introduction and focus on the bigger picture of the term Model-Based has led to various reactions. In particular, related to Model-Based Definition, the topic I am going to discuss in this post. Probably this is the topic where opinions vary the most as it is more close to the classical engineering and manufacturing processes.

What is Model-Based Definition?

There are various definitions of the term Model-Based Definition. Often the term Model-Based Enterprise is used in the same context. Where some people might stop thinking because the terminology is not 100 % aligned, I propose to focus on content. Let’s investigate what it is.

In the classical product lifecycle, a product is first designed for its purpose based on specifications. The product can be simple, purely mechanical or more complex, requiring mechanical design, electronic components, and software to work together. For the first case, I will focus on Model-Based definition, for the second case I recommend to start reading about Model-Based Systems Engineering approaches where the mechanical design is part of a more complex system.

Model-Based Definition for Mechanical Designs – the role of 2D

Historically designs were done on the drawing board in 2D. After the introduction of 2D CAD and later affordable 3D CAD systems at the end of the previous century, companies made a shift from designing in 2D towards 3D.  The advantages were clear. A much better understanding of products. Reading a 2D drawing requires special skills and sometimes they were not unambiguous. Therefore, 3D CAD models lead to increased efficiency and quality combined with the potential to reuse and standardize parts or sub-assemblies in a design.

These benefits were not always observed as complementary to the design (the engineering point of view), there was still the need to describe and define how a product needs to be manufactured. The manufacturing definition remained in a set of 2D drawings, and the 2D Drawings were the legal authority describing the product.

An interesting side note observation:
You will still see in industrial machinery companies, a pure EBOM does not exist, as designs were made to target the manufacturing drawings, not the 3D Model, engineering focused, intent. In this type of companies, the discussion EBOM/MBOM is challenging to explain.

Once the 3D Model becomes the authority, the split between design and manufacturing information will create extra work if you keep on creating 2D drawings for manufacturing.  It requires non-value added extra work, i.e., reinterpreting 3D data in 2D formats (extra engineering hours) and there is the risk for new errors (interpretations/versioning issues). This non-value added engineering time can add up to over 30 percent of the time spent by engineering. You can find these numbers through the links below this post. I will not be the MBD teacher in this post, I will focus on the business impact.

Model-Based Definition based on 3D

3D PDF Model

The logical step is to use the 3D Model and add manufacturing information attached to the model, through different views.  This can be Geometric Dimensioning and Tolerancing information (GF&T), Quality measurement information, Assembly instructions and more, all applied to different views of the model.



Of course here you become dependent on the chosen environments that support the combination of a 3D CAD model combined with annotation views that can be selected in the context of the model. There are existing standards how to annotate a model, find your most practical standard to your industry / Eco-system. Next, most CAD vendors and PLM vendors have their proprietary 3D formats and when you stay within their solution range working with a model-based definition will bring direct benefits, however …..

Model-Based Definition data standards

Every company needs to be able to combine and share information internally with other teams or with partners and suppliers, so a single vendor solution is a utopia. Even if your company has standardized themselves to one system, the next acquisition might be disturbing this dream. Anticipating for openness is crucial and when you start working according to a model-based definition, make sure that at least you have import or export capabilities from within your environment towards model-based definition standards.

The two major standards for model-based definition are 3DPDF and AP242/JT based. Don’t expect these standards to be complete. They will give you a good foundation for your model-based journey and make sure you are part of this journey. (Listen to the CIMdata webinar also listed below)

The Model-Based journey

It took almost 20 years for 3D CAD to become the mainstream for mechanical design. Engineers are now trained in 3D and think in 3D. Now it is time to start the journey to abandon 2D and connect engineering, manufacturing and service more efficient. Similar gains can be expected. Follow the links below this article, here already a quote from an old post by Isha Gupta Ray (Capgemini) related to MBD:

MBE Drivers: The need for consumption of 3D product data by non-engineering departments and the elimination of 2D drawing related rework and costs are driving companies to adopt 3D MBE methods rapidly. DoD predicts that the move away from 2D Drawings and into open and free-to-view 3D MBE documents will reduce the cost of its internal engineering activities by up to 30%, reduce the scrap and rework it currently deals with from its supply channel by nearly 20% and improves supplier response times by up to 50%.

Conclusion

Model-Based Definition is not as challenging as becoming a Model-Driven enterprise, that I described in my introduction post to this theme. It is a first step to challenge or energize your company to become a digital enterprise, as sharing between engineering and manufacturing needs to be orchestrated, even with your external parties. It is easy to do nothing and to wait till your company is pushed or pushed out, which would cause extra stress (or relieve forever).  For me Model-Based Definition is a first (baby) step towards a digital enterprise, warming-up your company to change a look at your data in a different way. Next when you combine parameters and simulation to your models, you will make the next step towards a model-driven digital enterprise.



Below a selection of links related to the theme of Model-Based Definition. If you feel I missed some crucial links, please provide them through the comments section of this post, and I will add them to the post if relevant.

Tech-Clarity: The How-to Guide for Adopting Model Based Definition (MBD)

Action Engineering: Articles, Blog plus training

Engineering.com: How Model-Based Definition Can Fix Your CAD Models

Lifecycle Insights: Quantifying the value of Model-Based definitions

CIMdata: Webinar on Model-Based Definition and Standards

Capgemini: Model-Based Enterprise with 3D PDF

if you want to learn more in-depth the advanced usage and potential of MBD, try to understand:

CIMdata: Minimum MDB and BOM definition with STEP AP 242

A month ago I announced to write a series of posts related to the various facets of Model-Based. As I do not want to write a book for a limited audience, I still believe blog posts are an excellent way to share knowledge and experience to a wider audience. Remember PLM is about sharing!

There are three downsides to this approach:

  • you have to chunk the information into pieces; my aim is not to exceed 1000 words per post
  • Isolated posts can be taken out of context (in a positive or negative way)
  • you do not become rich and famous for selling your book

Model-Based ways of working are a hot topic and crucial for a modern digital enterprise.  The modern digital enterprise does not exist yet to my knowledge, but the vision is there. Strategic consultancy firms are all active exploring and explaining the potential benefits – I have mentioned McKinsey / Accenture / Capgemini before.

In the domain of PLM, there is a bigger challenge as here we are suffering from the fact that the word “Model” immediately gets associated with a 3D Model. In addition to the 3D CAD Model, there is still a lot of useful legacy data that does not match with the concepts of a digital enterprise. I wrote and spoke about this topic a year ago. Among others at PI 2017 Berlin and you can  check this presentation on SlideShare: How digital transformation affects PLM

Back to the various aspects of Model-Based

My first post: Model-Based – an introduction described my intentions what I wanted to explain.  I got some interesting feedback and insights from my readers . Some of the people who responded understood that the crucial characteristic of the model-based enterprise is to use models to master a complex environment. Business Models, Mathematical Models, System Models are all part of a model-based enterprise, and none of them have a necessary relation to the 3D CAD model.

Why Model-Based?

Because this is an approach to master complex environments ! If you are studying the concepts for a digital enterprise model, it is complex. Artificial intelligence, predictive actions all need a model to deliver. The interaction and response related to my first blog post did not show any problems – only a positive mindset to further explore. For example, if you read this blog post from Contact, you will see the message came across very well: Model-Based in  Model-Based Systems Engineering – what’s up ?

Where the confusion started

My second post: Why Model-Based? The 3D CAD Model  was related to model-based, focusing on the various aspects related to the 3D CAD model, without going into all the details. In particular, in the PLM world, there is a lot of discussion around Model-Based Design or Model-Based Definition, where new concepts are discussed to connect engineering and manufacturing in an efficient and modern data-driven way. Lifecycle Insights, Action Engineering, Engineering.com, PTC,   Tech-Clarity and many more companies are publishing information related to the model-based engineering phase.

Here is was surprised by Oleg’s blog with his post Model-Based Confusion in 3D CAD and PLM.

If you read his post, you get the impression that the model-based approach is just a marketing issue instead of a significant change towards a digital enterprise. I quote:

Here is the thing… I don’t see much difference between saying PLM-CAD integration sharing data and information for downstream processes and “model-driven” data sharing. It might be a terminology thing, but data is managed by CAD-PLM tools today and accessed by people and other services. This is how things are working today. If model-driven is an approach to replace 2D drawings, I can see it. However, 2D replacement is something that I’ve heard 20 years ago. However, 2D drawings are still massively used by manufacturing companies despite some promises made by CAD vendors long time ago.

I was surprised by the simplicity of this quote. As if CAD vendors are responsible for new ways of working. In particular, automotive and aerospace companies are pushing for a model-based connection between engineering and manufacturing to increase quality, time to market and reduced handling costs. The model-based definition is not just a marketing issue as you can read from benefits reported by Jennifer Herron (Re-use your CAD – the model-based CAD handbook – describing practices and benefits already in 2013) or Tech-Clarity (The How-To Guide for adopting model-based definition – describing practices and benefits – sponsored by SolidWorks)

Oleg’s post unleashed several reactions of people who shared his opinion (read the comments here). They are all confused, t is all about marketing / let’s not change / too complex. Responses you usually hear from a generation that does not feel and understand the new approaches of a digital enterprise. If you are in the field working with multiple customers trying to understand the benefits of model-based definition, you would not worry about terminology – you would try to understand it and make it work.

Model-Based – just marketing?

In his post, Oleg refers to CIMdata’ s explanation of the various aspects of model-based in the context of PLM. Instead of referring to the meaning of the various acronyms, Peter Bilello (CIMdata) presented at the latest PDT conference (Oct 2017 – Gothenburg) an excellent story related to the various aspects of the model-based aspects, actually the whole conference was dedicated to the various aspects of a Model-Based Enterprise illustrates that it is not a vendor marketing issue. You can read my comments from the vendor-neutral conference here: The weekend after PDT Europe 2017 Part 1 and Part 2.

There were some dialogues on LinkedIn this weekend, and I promised to publish this post first before continuing on the other aspects of a model-based enterprise.  Just today Oleg published a secondary post related to this topic: Model-Based marketing in CAD and PLM, where again the tone and blame is to the PLM/CAD vendors, as you can see from his conclusion:

I can see “mode-based” as a new and very interesting wave of marketing in 3D CAD and PLM.  However, it is not pure marketing and it has some rational. The rational part of model-based approach is to have information model combined from 3D design and all connected data element. Such model can be used as a foundation for design, engineering, manufacturing, support, maintenance. Pretty much everything we do. It is hard to create such model and it is hard to combine a functional solution from existing packages and products. You should think how to combine multiple CAD systems, PLM platforms and many other things together. It requires standards. It requires from people to change. And it requires changing of status quo. New approaches in data management can change siloed world of 3D CAD and PLM. It is hard, but nothing to do with slides that will bring shiny words “model-base”. Without changing of technology and people, it will remain as a history of marketing

Again it shows the narrow mindset on the future of a model-based enterprise. When it comes to standards I recommend you to register and watch CIMdata’s educational webinar called: Model-Based Enterprise and Standards – you need to register. John MacKrell CIMdata’s chairman gives an excellent overview and status of model-based enterprise initiative.  After having studied and digested all the links in this post, I challenge you to make your mind up. The picture below comes from John’s presentation, an illustration where we are with model-based definition currently



Conclusion

The challenge of modern businesses is that too often we conclude too fast on complex issues or we frame new developments because they do not fit our purpose. You know it from politics. Be aware it is also valid in the world of PLM. Innovation and a path to a modern digital enterprise do not come easy – you need to invest and learn all the aspects. To be continued (and I do not have all the answers either)

I wrote in my previous posts about the various aspects of a model-based enterprise. In case you missed this post you can find it here: Model-Based an introduction. In this post I will zoom in on the aspects related to the 3D model, probably in the context of PLM, the most anticipated approach.

3D CAD vs 3D CAD Model

At the time 3D CAD was introduced for the mid-market, the main reason why 3D CAD was introduced was to provide a better understanding of the designed product. Visualization and creating cross-sections of the design became easy although the “old” generation of 2D draftsmen had to a challenge to transform their way of working. This lead often to 3D CAD models setup with the mindset to generate 2D Manufacturing drawings,  not taking real benefits from the 3D CAD Model. Let’s first focus on Model-Based Definition.

Model-Based Definition

We talk about Model-Based Definition when the product and manufacturing information is embedded / connected to the 3D CAD model, allowing the same source of information to be used downstream for manufacturing, analysis and inspection. The embedded information normally contains geometric dimensions, annotations, surface finish and material specifications. Instead of generating easy to distribute 2D drawings, you would be using the 3D model now with its embedded information.

According to an eBook, sponsored by SolidWorks and published by Tech-Clarity: “The How-to Guide for Adopting Model-Based Definition MBD”, Tech-Clarity’s research discovered that 33 percent of design time is spent on drawing generation. Imagine you do not need this time anymore to specify manufacturing processes and operations.  Does this mean the design activities can be reduced by 30 % ? Probably not, the time could be used to spend on design alternatives too, at the end contributing to better designs.

Still this is not the reason why companies would move to MBD. Companies that have implemented MBD report fewer manufacturing mistakes/less rework (61 %) – here is where the value becomes visible. In addition, improved communication with suppliers was reported by 50 % of the companies. More clarity in the communication, however as some of the suppliers are not used to MBD either, this excuse is used not to implement MBD. Instead of creating a win-win situation a status-quo is created.

Read the eBook to demystify Model-Based Definition and realize that although it might look like a complex change, within 8 to 9 months the company might have gone through this change, assuming you have found the proper trainers / coaches for that.

When discussion a roadmap towards a digital enterprise, this is one of the “easier” steps to take as it does not force the organization to change their primary processes. They become more efficient, lean and integrated, delivering rapid benefits within a year.

In the same context of MBD, in my post: Digital PLM requires a Model-Based Enterprise I referred to two articles in engineering.com written by Dick Bourke with the support from Jennifer Herron.  The first article: How Model-based Definition Can Fix Your CAD Models digs into more detail and provides additional insights into benefits realizable by implementing MBD. As I am not the expert, I would recommend if you agree on the benefits and necessity for your company’s future, find the right literature. There is a lot of information related to MBD coming from vendors but also vendor-neutral sources. Technology Is not the issue. You just have to study, digest and implement it  with your suppliers.

Beyond MDB using a 3D CAD Model

Although the post gets long, it is crucial to understand that the 3D CAD model should also be built in a more sophisticated manner. Using parameters in the model instead of hard-coded values allows the model to be used and interact with other disciplines in a digital manner.

A parametric model, combined with business rules can be accessed and controlled by other applications in a digital enterprise. In this way, without the intervention of individuals a set of product variants can be managed and not only from the design point of view. Geometry and manufacturing parameters are also connected and accessible. This is one of the concepts where Industry 4.0 is focusing on: intelligent and flexible manufacturing by exchanging parameters

The 3D CAD Model and Simulation

The last (short) part related to the 3D CAD Model is about its relation to simulation. If you do no use simulation together with your 3D CAD Models, you are still designing in the past. No real advantage between 2D and 3D, just better understanding?

In engineering we often talk about Form, Fit and Function – the three dimensions to decide on a change.  With 2D (and 3D without simulation) we manage Form and Fit disconnected from Function. Once we use 3D combined with Simulation we are able to manage these three parameters in relation.

For example, when designing product, first simulations can provide direct feedback on shape and dimension constraints. Where to save material costs, choose from another design solution? The ultimate approach is Generative Design where the Functional constraints and the Fit are the given constraints and the Form is optimized based on artificial intelligence rules.

In case a company has a close relation between 3D Design and Simulation, the concept of Design of Experiments (DOE) will help to find the optimal product constraints. The more integrated the 3D CAD model and the simulation are, the more efficient alternatives can be evaluated and optimized.

Conclusion

In this post we focused on model-based in relation to the 3D CAD Model. Without going to the expert level for each of the topics discussed, I hope it creates the interest and enthusiasm for further investment in model-based practices.  One commonality for all model-based practices: it is about parameters. Parameters provide digital continuity where each discipline (design, simulation, manufacturing) can build upon in almost real-time without the need for people to convert or adjust information. Digital Continuity – one of the characteristics of the future digital enterprise















The recent years I have been mentioning several times addressing the term model-based in the context of a modern, digital enterprise. Posts like: Digital PLM requires a model-based enterprise (Sept 2016) or Item-Centric or Model-Centric (Sept 2017) describe some of the aspects of a model-based approach. And if you follow the PLM vendors in their marketing messages, everyone seems to be looking for a model-based environment.

This is however in big contrast with reality in the field. In February this year I moderated a focus group related to PLM and the Model-Based approach and the main conclusion from the audience was that everyone was looking at it, and only a few started practicing. Therefore, I promised to provide some step-by-step education related to model-based as like PLM we need to get a grip on what it means and how it impacts your company. As I am not an academic person, it will be a little bit like model-based for dummies, however as model-based in all aspects is not yet a wide-spread common practice, we are all learning.

What is a Model?

The word Model has various meanings and this is often the first confusion when people speak about Model-Based. The two main interpretations in the context of PLM are:

  • A Model represents a 3D CAD Model – a virtual definition of a physical product
  • A Model represents a scientific / mathematical model

And although these are the two main interpretations there are more aspects to look at model-based in the context of a digital enterprise. Let’s explore the 3D CAD Model first

The role of the 3D CAD Model in a digital enterprise

Just designing a product in 3D and then generating 2D drawings for manufacturing is not really game-changing and bringing big benefits. 3D Models provide a better understanding of the product, mechanical simulations allow the engineer to discover clashes and/or conflicts and this approach will contribute to a better understanding of the form & fit of a product. Old generations of designers know how to read a 2D drawing and in their mind understand the 3D Model.

Modern generations of designers are no longer trained to start from 2D, so their way of thinking is related 3D modeling. Unfortunate businesses, in particular when acting in Eco-systems with suppliers, still rely on the 2D definition as the legal document.  The 3D Model has brought some quality improvements and these benefits already justify most of the companies to design in 3D, still it is not the revolution a model-based enterprise can bring.

A model-based enterprise has to rely on data, so the 3D Model should rely on parameters that allow other applications to read them. These parameters can contribute to simulation analysis and product optimization or they can contribute to manufacturing. In both cases the parameters provide data continuity between the various disciplines, eliminating the need to create new representations in different formats. I will come back in a future post to the requirements for the 3D CAD model in the context of the model-based enterprise, where I will zoom in on Model-Based Definition and the concepts of Industry 4.0.

The role of mathematical models in a digital enterprise

The mathematical model of a product allows companies to analyze and optimize the behavior of a product. When companies design a product they often start from a conceptual model and by running simulations they can optimize the product and define low-level requirements within a range that optimizes the product performance. The relation between design and simulation in a virtual model is crucial to be as efficient as possible. In the current ways of working, often design and simulation are not integrated and therefore the amount of simulations is relative low, as time-to-market is the key driver to introduce a new product.

In a digital enterprise, design and simulations are linked through parameters, allowing companies to iterate and select the optimal solution for the market quickly. This part is closely related to model-based systems engineering (MBSE) , where the focus is on defining complex systems. In the context of MBSE I will also zoom in on the relation between hardware and software, which at the end will deliver the desired functionality for the customer. Again in this part we will zoom in on the importance of having a parameter model, to ensure digital continuity.

Digital Twin

There is still a debate if the Digital Twin is part of PLM or should be connected to PLM. A digital twin can be based on a set of parameters that represent the product performance in the field. There is no need to have a 3D representation, despite the fact that many marketing videos always show a virtual image to visualize the twin.

Depending on the business desire, there can be various digital twins for the same products in the field, all depending on the parameters that you want to monitor. Again it is about passing parameters, in this case from the field back to R&D and these parameters should be passed in a digital manner. In a future post I will zoom in on the targets and benefits of the digital twin.

Conclusion

There are various aspects to consider related to “model-based”.  The common thread for each of the aspects is related to PARAMETERS.  The more you can work with parameters to connect the various usages of a product/system, the closer you are related to the digital enterprise. The real advantages of a digital enterprise are speed (information available in real-time), end-to-end visibility (as data is not locked in files / closed systems).

PARAMETERS the objects to create digital continuity









When PLM – Product Lifecycle Management – was introduced, one of the main drivers was to provide an infrastructure for collaboration and for sharing product information across the whole lifecycle. The top picture shows my impression of what PLM could mean for an organization at that time. The PLM circle was showing a sequential process from concept, through planning, development, manufacturing towards after sales and/or services when relevant. PLM would provide centralization and continuity of data. Through this continuity we could break down the information silos in a company.

Why do we want to break down the silos?

You might ask yourself what is wrong with silos if they perform in a consistent matter? Oleg Shilovitsky recently wrote about it: How PLM can separate data and organization silos.  Read the post for the full details, I will stay at Oleg’s conclusion:

Keep process and organizational silos, but break data silos. This is should be a new mantra by new PLM organization in 21st century. How to help designers, manufacturing planners and support engineers to stay on the same BOM? By resolving this problem, organization will preserve current functional structure, but will make their decisions extremely data drive and efficient. The new role of PLM is to keep organizational and process silos, but connect data silos. This is a place where new cloud based multi-tenant technologies will play key role in the future organization transformation from the vision of no silo extended enterprise to organized functional silos connected by common understanding of data.

When I read this post I had so much to comment, which lead to this post. Let me share my thoughts related to this conclusion and hopefully it helps in future discussions. Feel free to join the discussion:

Keep process and organizational silos, but break data silos. This is should be a new mantra by new PLM organization in 21st century

For me “Keep process and organizational silos ….. “ is exactly the current state of classical PLM, where PLM concepts are implemented to provide data continuity within a siloed organization. When you can stay close to the existing processes the implementation becomes easier. Less business change needed and mainly a focus on efficiency gains by creating access to information.

Most companies do not want to build their data continuity themselves and therefore select and implement a PLM system that provides the data continuity, currently mainly around the various BOM-views. By selecting a PLM system, you have a lot of data integration done for you by the vendor. Perhaps not as user-friendly as every user would expect, however no company has been able to build a 100% user-friendly PLM system yet, which is the big challenge for all enterprise systems. Therefore PLM vendors provide a lot of data continuity for you without the need for your company to take responsibility for this.

And if you know SAP, they go even further. Their mantra is that when using SAP PLM, you even do not need to integrate with ERP.  You can still have long discussions with companies when it comes to PLM and ERP integrations.  The main complexity is not the technical interface but the agreement who is responsible for which data sets during the product lifecycle. This should be clarified even before you start talking about a technical implementation. SAP claims that this effort is not needed in their environment, however they just shift the problem more towards the CAD-side. Engineers do not feel comfortable with SAP PLM when engineering is driving the success of the company. It is like the Swiss knife; every tool is there but do you want to use it for your daily work?

In theory a company does not need to buy a PLM system. You could build your own PLM-system, based on existing infrastructure capabilities. CAD integrations might be trickier, however this you could solve by connecting to their native environments.  For example, Microsoft presented at several PDT conferences an end-to-end PLM story based on Microsoft technology.  Microsoft “talks PLM” during these conferences, but does not deliver a PLM-system – they deliver the technologies.

The real 21st-century paradigm

What is really needed for the 21st century is to break down the organizational silos as current ways of working are becoming less and less applicable to a modern enterprise. The usage of software has the major impact on how we can work in the future. Software does not follow the linear product process. Software comes with incremental deliveries all the time and yes the software requires still hardware to perform. Modern enterprises try to become agile, being able to react quickly to trends and innovation options to bring higher and different value to their customers.  Related to product innovation this means that the linear, sequential go-to-market process is too slow, requires too much data manipulation by non-value added activities.

All leading companies in the industry are learning to work in a more agile mode with multidisciplinary teams that work like startups. Find an incremental benefit, rapidly develop test and interact with the market and deliver it. These teams require real-time data coming from all stakeholders, therefore the need for data continuity. But also the need for data quality as there is no time to validate data all the time – too expensive – too slow.

Probably these teams will not collaborate along the various BOM-views, but more along digital models, both describing product specifications and system behavior. The BOM is not the best interface to share system information. The model-based enterprise with its various representations is more likely to be the backbone for the new future in the 21st century. I wrote about this several times, e.g. item-centric or model-centric.

And New cloud-based multi-tenant technologies …

As Oleg writes in his conclusion:

This is a place where new cloud-based multi-tenant technologies will play key role in the future organization transformation from the vision of no silo extended enterprise to organized functional silos connected by common understanding of data.

From the academic point of view, I see the beauty of new cloud-based multi-tenant technologies. Quickly build an environment that provides information for specific roles within the organization – however will this view be complete enough?  What about data dictionaries or is every integration a customization?

When talking with companies in the real world, they are not driven by technology – they are driven by processes. They do not like to break down the silos as it creates discomfort and the need for business transformation. And there is no clear answer at this moment. What is clear that leading companies invest in business change first before looking into the technology.

Conclusion

Sometimes too much academic and wishful thinking from technology providers is creating excitement.  Technology is not the biggest game changer for the 21st century. It will be the new ways of working and business models related to a digital enterprise that require breaking organizational silos. And these new processes will create the demand for new technologies, not the other way around.

Break down the walls !

At the moment this post is published I have had time to digest the latest PLMx conference organized by MarketKey. See the agenda here. For me it was a conference with mixed feelings this time and I will share more details a little further on.

Networking during the conference was excellent, good quality of conversations, however the number of people attending was smaller than previous conferences, perhaps due to too much diversification in the PI conferences?

There were several inspiring sessions and as I participated in three sessions myself, I missed a lot of potential exciting sessions that were in parallel at the same time. I believe four parallel tracks is too much and downloading the presentations later does not give you the real story.  Now some of the notable sessions I attended:

Building a Better Urban Mobility Future

The first keynote session was meant to inspire us and think of solving issues differently. Lewis Horne from a Swedish automotive startup explained their different approach to designing an electrical vehicle. Not based on classical paradigms – you do not need a steering wheel – you can navigate differently. And switching the indicator on when going left or right is now a swipe. Of course these were not the only differences.

Unity will not certify for the highest safety classes like other vehicles as car safety rules are a lot based on mechanical / human handling and responses. A fully computerized and full of sensors has complete different dynamics. And a light city car does not ride on the high-speed way. Based on the first prototype there are already more than 1000 pre-orders but Unity does not have a manufacturing facility. This will be franchised. Unity used the Apple mode – focus on an unmatched user-experience instead of manufacturability. Let’s see what happens when the first Unity’s start riding – current target prices 20.000 Euro. Will it be the new hype for modern citizens?

Focus on quality – not on happy engineers

Not only the title of this paragraph but also other statements were made by Hilmer Brunn, head of global PLM from Mettler-Toledo related to their PLM implementation strategy.  As Hilmer stated:

We should not focus to give engineers more time to design only. The job of engineering is more comprehensive than just creating designs. Engineers also need to solve issues that are related to their design – not leave it to the others.

Another interesting statement:

As long as you do not connect simulation to your design in 3D, you are actually working with 3D as if you do it with 2D. The value of 3D is more than just representation of geometry.

And the last quote I want to share from Hilmer was again related to engineering.

Engineering should consider themselves as a service provider of information to the rest of the company, providing the full information associated with a design, instead of behaving like extreme, intelligent people who need more resources to translate and complete their work.

Grand statements although during Q&A it became clear that also Mettler-Toledo did not have the magic bullet to get an organization work integrated.

Working towards a Model-Based Enterprise with PLM

I consider Model-Based practices as one of the essential needs for future PLM as this approach reduces the amount of derived information related to a product/ system. And it provides a digital continuity. In the last PDT conference in Gothenburg this topic was shared on a quit extensive matter. Have a read to fresh-up your memory here:  The weekend after PDT Europe – part 1 and part 2

The focus group  which I moderated was with approximate 20 attendees and the majority was looking for getting a better understanding what model-based would mean for their organization. Therefore, the discussion was at the end more around areas where a few persons had the experience while others still tried to grasp the concepts. For me a point to take action related to education and in future posts I will go deeper into the basics.

PLMPulse Survey results and panel discussion

Nick Leeder presented the context of the PLMPulse survey and the results in a precise manner, where perhaps the result was not that surprising to the audience as many of us are involved in PLM. Two recurring points: PLM is still considered as an engineering tool and: The value related to PLM is most of the time not clear. You can register and download the full report from here.

Next Nick lead a panel discussion where people from the audience could participate.  And here we got into a negative spiral where it became an inward-looking discussion why PLM has never been able to show the value and get out of the engineering domain. It was a someone said like an anonymous PLM meeting where members stood up and confessed they were also part of the group that could not change this behavior.

Was it the time of the day? Was it the mood of the audience? Too much old experiences?  I believe it has to do with the fact that in PLM projects and conferences we focus too much on what we do and how we do things, not connecting it to tangible benefits that are recognized at the board level. And we will see an example later.

Solar Stratos

The food and drinks at the end of day 1 probably washed away the PLMPulse feedback session and Raphael Domjan inspired us with his SolarStratos project – a mission to develop a plane that can fly on solar energy on the heights of the stratosphere. Raphael is working hard with a team now to get there.

Designing an airplane, more a glider, that can take off en reach the stratosphere on solar energy requires solving a combination of so many different challenges. The first test flight reached an altitude of 500 m, but you can imagine challenges with the stratosphere – lack of oxygen / air pressure need to be solved. Raphael is looking for funding and you can find more details here. Back to the relative easy PLM challenges

The future of PLM Consultancy

Together with Oleg Shilovitsky we had a discussion related to the ways PLM could be realized in different manners thanks to changing technology. The dialogue started through our blogs – read it here. In this session there was a good dialogue with the audience and MarketKey promised to share the video recording of this session soon.  Stay tuned to Oleg’s blog or my blog and you can watch it.

PLM in the context of digitization

This was my main personal contribution to the conference. Sharing insights why we have to approach PLM in a different manner. Not the classical linear engineering approach but as a mix of system of record and system of engagement. You can see the full presentation on SlideShare here.

My main conclusions are that PLM consultants / experts focus too much on what and how they do PLM, where the connection to WHY is missing. (See also my post PLM WHY?).

In addition I defended the statement that old and new PLM are incompatible and therefore you need to accept they will exist both in your organization. For a while or for a long time, depending on your product lifecycle.  In order to reduce the gap between old and new PLM, there is a need for data governance, model-based ways of working, which allow the company to connect at some stages the old/record data and the new data. And don’t do pilots anymore experimenting new ways of working and then stop because the next step seems to be overwhelming. Start your projects in small, multidisciplinary teams and make them real. The only way to be faster in the future.

PLM in Manufacturing as Backbone of the Smart Factory

Susanne Lauda, Director, Global Advanced Manufacturing Technology, AGCO Corporation provided an overview related to AGCO’s new PLM journey and how they were benefiting from a digital thread towards manufacturing. It felt like a smooth vendor demo as everything looked nice and reasonable. It was all about the WHAT. However two points that brought the extra:

When moving to the new system the tried to bring in the data from an existing product into then new system. According to Susanne a waste of time as the data required so much rework – there was no real value added for that. This confirms again my statement that old and new PLM are incompatible and one should not try to unify everything again in one system.

Second, I got excited at the end when we discussed the WHY for PLM and the business value of PLM. Here Suzanne mentioned PLM started as a “must-do strategic” project.  PLM lead to a reduction of time to market with almost 50 %. Suzanne did not give exact number, but you can imagine I have heard these numbers from other companies too. Why aren’t we able to connect these benefits in the mindset of the management to PLM ? Perhaps still too much engineering focused.

Next Susanne explained that they investigated the cost for quality for their manufacturing plants. What if something was produced wrong, the wrong parts were ordered, the delays to fix it, the changes needed to be made on the shop floor?  These results were so high that people were even afraid to report them. This is the case at many companies I worked with – even their PLM consultants do not receive these numbers – you just have to imagine they are big.

At AGCO they were able to reduce the cost for quality in a significant manner and Susanne explain that PLM was a main contributor to that success. However, success always has many fathers – so if your PLM team does not claim loud (and we are modest people not used to talk finance) – the success will not be recognized.

PLM’s Place Within an Enterprise Application Architecture

Peter Bilello from CIMData in the closing keynote speech gave an excellent summary and overview of where and which capabilities fit in an enterprise architecture and the positioning of a product innovation platform. A blueprint that can be used for companies to grasp the holistic view before jumping into the details of the tools.

Conclusion

PLMx Hamburg 2018 was an event with valuable highlights for me and potential I missed several more due to the fact of parallel streams. I hope to catch-up with these sessions in the upcoming month and share interesting thoughts that I discover with you. What remains crucial I believe for all vendor-neutral events is to find new blood. New companies, new experiences that are focused on the future of PLM and connect to the WHY or the WHAT WE LEARNED values.

If you have followed my blog over the past 10 years, I hope you realize that I am always trying to bring sense to the nonsense and still looking into the future where new opportunities are imagined. Perhaps due to my Dutch background (our motto: try to be normal – do not stand out) and the influence of working with Israeli’s (a country where almost everyone is a startup).

Given this background, I enjoy the current discussion with Oleg Shilovitsky related to potential PLM disruptions. We worked for many years together at SmarTeam, a PDM/PLM disruptor at that time, in the previous century. Oleg has continued his passion for introducing potential disruptive solutions  (Inforbix / OpenBOM) where I got more and more intrigued by human behavior related to PLM. For that reason, I have the human brain in my logo.

Recently we started our “The death of ….” Dialogue, with the following episodes:

Jan 14thHow to democratize PLM knowledge and disrupt traditional consulting experience

Jan 21stThe death of PLM Consultancy

Jan 22ndWhy PLM consultants are questioning new tools and asking about cloud exit strategy?

Here is episode 4  – PLM Consultants are still alive and have an exit strategy

Where we agree

We agreed on the fact that traditional consultancy practices related to PLM ranking and selection processes are out of time. The Forester Wave publication was the cause of our discussion. For two reasons:

  1. All major PLM systems cover for 80 percent the same functionalities. Therefore there is no need to build, send and evaluate lengthy requirements lists to all potential candidates and then recommend on the preferred vendor. Waste of time as the besides the requirements there is much more to evaluate than just performing tool selection.
  2. Many major consultancy firms have PLM practices, most of the time related to the major PLM providers. Selecting one of the major vendors is usually not a problem for your reputation, therefore the importance of these rankings. Consultancy firms will almost never recommend disruptive tool-sets.

PLM businesses transformation

At this point, we are communicating at a different wavelength. Oleg talks about PLM business transformation as follows:

Cloud is transforming PLM business. Large on-premise PLM projects require large capital budget. It is a very good foundation for existing PLM consulting business. SaaS subscription is a new business model and it can be disruptive for lucrative consulting deals. Usually, you can see a lot of resistance when somebody is disrupting your business models. We’ve seen it in many places and industries. It happened with advertising, telecom and transportation. The time is coming to change PLM, engineering and manufacturing software and business.

I consider new business models less relevant compared to the need for a PLM practice transformation. Tools like Dropbox, perhaps disruptive for PDM systems, are tools that implement previous century methodology (document-driven / file-based models). We are moving from item-centric towards a model-driven future.

The current level of PLM practices is related to an item-centric approach, the domain where also OpenBOM is bringing disruption.
The future, however, is about managing complex products, where products are actually systems, a combination of hardware and software. Hardware and software have a complete different lifecycle, and all major PLM vendors are discovering an overall solution concept to incorporate both hardware and software. If you cannot manage software in the context of hardware in the future, you are at risk.  Each PLM vendor has a different focus area due to their technology history. I will address this topic during the upcoming PLMx conference in Hamburg. For a model-driven enterprise, I do not see an existing working combination of disruptors yet.

Cloud security and Cloud exit strategy

Oleg does not really see the impact of the cloud as related to the potential death of PLM consulting as you can read here:

I agree, cloud might be still not for everyone. But the adoption of cloud is growing and it is becoming a viable business model and technology for many companies. I wonder how “cloud” problem is related to the discussion about the death of PLM consulting. And…  here is my take on this. It is all about business model transformation.

I am not convinced that in the PLM cloud is the only viable business model. Imagine an on-premise rigid PLM system. Part of the cloud-based implementation benefits come from low upfront costs and scalable IT. However, cloud also pushes companies to defend a no-customization strategy – configuration of the user interface only.  This is a “secret” benefit for cloud PLM vendors as they can say “NO” to the end users of course within given usability constraints. Saying “NO” to the customer is lesson one for every current PLM implementation as everyone knows the problem of costly upgrades later

Also, make a 5-10 years cost evaluation of your solution and take the risk of raising subscription fees into account. No vendor will drop the price unless forced by the outside world. The initial benefits will be paid back later because of the other business model.

Cloud exit strategy and standards

When you make a PLM assessment, and usually experienced PLM consultants do this, there is a need to consider an exit strategy. What happens if your current PLM cloud vendor(s) stops to exist or migrate to a new generation of technology and data-modeling? Every time when new technology was introduced, we thought it was going to be THE future. The future is unpredictable. However, I can predict that in 10 years from now we live with different PLM concepts.

There will be changes and migrations and cloud PLM vendors will never promote standardized exports methods (unless forced) to liberate the data in the system. Export tools could be a niche market for PLM partners, who understand data standards. Håkan Kårdén, no finders fee required, however, Eurostep has the experience in-house.



Free downloads – low barriers to start

A significant difference in opinion between Oleg and me is Oleg’s belief in bottom-up, DIY PLM as part of PLM democratization and my belief in top-down business transformation supported by PLM. When talking about Aras, Autodesk, and OpenBOM,  Oleg states:

All these tools have one thing in common. You can get the tool or cloud services for free and try it by yourself before buying. You can do it with Aras Innovator, which can be downloaded for free using enterprise open source. You can subscribe for Autodesk Fusion Lifecycle and OpenBOM for trial and free subscriptions. It is different from traditional on-premise PLM tools provided by big PLM players. These tools require months and sometimes even years of planning and implementation including business consulting and services.

My experience with SmarTeam might influence this discussion. SmarTeam was also a disruptive PDM solution thanks to its easy data-modeling and Microsoft-based customization capabilities like Aras. Customers and implementers could build what they want, you only needed to know Visual Basic. As I have supported the field mitigating installed SmarTeam implementations, often the problem was SmarTeam has been implemented as a system replicating/automating current practices.

Here Henry Ford’s statement as shown below applies:

Implementations became troublesome when SmarTeam provided new and similar business logic. Customers needed to decide to use OOTB features and de-customize or not benefits from new standard capabilities. SmarTeam had an excellent business model for service providers and IT-hobbyists/professionals in companies. Upgrade-able SmarTeam implementations where those that remained close to the core, but meanwhile we were 5 – 8 years further down the line.

I believe we still need consultants to help companies to tell and coach them towards new ways of working related to the current digitization. Twenty years old concepts won’t work anymore. Consultants need a digital mindset and think holistic. Fitting technology and tools will be there in the future.

Conclusion

The discussion is not over, and as I reached already more than 1000 words, I will stop. Too many words already for a modern pitch, not enough for a balanced debate. Oleg and I will continue in Hamburg, and we both hope others will chime in, providing balanced insights in this discussion.

To be continued …..?



Translate

Email subscription to this blog

Advertisements
%d bloggers like this:
